Mondraker Crusher RR

Mondraker Crusher RR
$8,999.00
Color: Translucent Red
Size: Select size
Wheel Size: 29-inch
Please select options Unavailable

Details

IT IS THE ONLY ONE WITH A SHIMANO XT DI2 CHAINSET WITH ‘FREE SHIFT’.. The CRUSHER RR has an Öhlins RXF 38 M.2 29 fork, a Shimano Deore XT Di2 chainset, Shimano Deore XT M8120 brakes, an ONOFF Pija dropper seatpost (with between 125mm - 200mm of travel depending on frame size) and Maxxis Minion DHF/DHR II 2.6” EXO+ tyres. Available in the spectacular ‘Translucent Red Carbon - Black - Racing Silver’ colourway.

Sizes:
Frame sizeSmallMediumLargeX-Large
Seattube length380mm 420mm450mm490mm
Toptube length605mm 625mm650mm670mm
Bottom bracket drop-25mm -25mm-25mm-25mm
Bottom bracket height350mm 350mm350mm350mm
Chainstay length455mm 455mm455mm455mm
Seat tube angle73.5º 73.5º73.5º73.5º
Effective seattube angle77° 77°77°77°
Headtube angle65º 65º65º65º
Fork Offset44 mm 44mm44mm44mm
Wheelbase1227mm 1247mm1267mm1387mm
Headtube length110mm 110mm130mm130mm
Reach450mm 470mm490mm510mm
Stack622mm 622mm640mm640mm

Specs

Motor Motor: Shimano STEPS EP801
Pedals Sold Separately
Battery Battery: Simplo internal 720Wh G3
Controller/Display Display: Shimano EN600
Fork Fork: Öhlins RXF 38 M.2 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber
Hubs Front Hub: Mavic, Boost 15x110mm, Center Lock ; Rear Hub: Mavic, Boost 12x148mm, ID360 Ratchet system, Center Lock, MS freehub
Rims Rims: Mavic E-Deemax S 29, 30mm internal width, Maxtal welded, PFP, tubeless, 28 spokes
Stem Stem: Onoff Krypton FG 30mm, CNC, 31.8mm barbore
Chain Chain: Shimano Deore XT M8100
Frame Frame: Crusher Stealth Air Carbon front triangle, Stealth Alloy rear triangle, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, integrated internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Tires Front Tire: Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead ; Rear Tire: Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Brakes Front Brake: Shimano Deore XT M8120, 4-piston caliper, MT-800 Ice-Tech 203mm Center Lock ; Rear Brake: Shimano Deore XT M8120, 4-piston caliper, MT-810 Ice-Tech 203mm Center Lock
Saddle Saddle: FIZIK Terra Aidon X5 145mm
Spokes Spokes: Mavic straight-pull double butted, contactless lacing
Headset Headset: Acros AZF-601 R1 Block Lock 120°, ZS44/28.6 top, ZS56/40 bottom
Crankset Crankset: Shimano Steps XT FC-8150 ebike, 165mm
Seatpost Seatpost: Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm + SHIMANO SL-MT800-IL lever
Shifters Shift Levers: Shimano XT Di2 SW-M8150
Chainrings Rings: Shimano EP801, 34T, 104 BCD
Handlebars Handlebar: Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Rear Shock Rear Shock: Öhlins TTX Air 205X65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
Tape/Grips Grips: Onoff Desert, 1lock-on, 135mm
Brake Levers Brake Lever: Shimano Deore XT M8120
Rear Derailleur Rear Derrailleur: Shimano Deore XT M8150-GS Di2 12s shadow plus, direct mount
Cassette/Freewheel Cassette: Shimano Deore XT M8100, 10-51 12s

* Subject to change without notice.

Part Numbers

Option UPC MPN
Translucent Red / X-Large / 29-inch 8435392885300 010.24US372
Translucent Red / Large / 29-inch 8435392887380 010.24US371
Translucent Red / Small / 29-inch 8435392885270 010.24US369
Translucent Red / Medium / 29-inch 8435392885287 010.24US370
