Niner RLT 9 Steel 4-Star GRX 1x

Niner RLT 9 Steel 4-Star GRX 1x
$2,950.00
$4,099.00
Color: Black/Bronze
Size: Select size
Please select options Unavailable
This item may be picked up in-store by appointment; call 480-744-5940 or email customerservice@velozoom.com to schedule.

Details

The RLT 9 Steel is for the purist, the rider who's after the classic aesthetics of smooth, supple Reynolds 853 steel. With plenty of mounts for bags and gear, whether it's on pavement or gravel road, this bike craves long adventures.

bike frame with labeled dimensions
Bike Sizes:
47cm50cm53cm56cm59cm62cm
A. Reach (mm) 365 367 375 384 398 406
B. Stack (mm) 543 558 579 597 615 636
C. Standover (mm) 735 757 781 809 835 860
D. Effective Top Tube (mm) 510 525 545 565 585 605
E. Head Tube Angle 70° 70.5° 71° 71.5° 72° 72.5°
F. Head Tube Length (mm) 110 125 145 165 185 205
G. Seat Tube Angle 74.5° 74° 73.5° 73° 73° 72.5°
H. Seat Tube Length (mm) 470 500 530 560 590 620
J. Bottom Bracket Drop (mm) 75 75 75 70 70 70
K. Fork Rake/Offset (mm) 45 45 45 45 45 45
M. Wheelbase (mm) 1008 1015 1025 1038 1053 1062
N. Front to Center (mm) 583 589 600 611 626 635
O. Chainstay Length (mm) 430 430 430 430 430 430

Specs

Frame REYNOLDS 853 STEEL; EXTERNAL CABLE ROUTING; INTEGRATED BOTTLE, BAG, RACK AND FENDER MOUNTS; FLAT MOUNT; 12X142 THRU AXLE
Fork NINER RDO FULL CARBON; INTEGRATED BOTTLE, BAG, RACK AND FENDER MOUNTS; INTERNAL CABLE ROUTING; FLAT MOUNT; 12X100 THRU AXLE
Rims DT Swiss G 1800 SPLINE, 700c aluminum clincher
Hubs DT Swiss 370 Centerlock with 3-Pawl
Spokes DT Swiss aero comp wide straight pull
Axles Front: 12x100mm thru axle
Rear: 12x142mm thru axle
Tires SCHWALBE G-ONE ALLROUND EVO SUPER TERRAIN, TLE, ADDIX SPEEDGRIP, 700 X 45
Bottom Bracket EASTON PF30
Crankset EASTON EC90 CARBON 40T (47/50 - 170MM, 53/56 - 172.5MM, 59/62 - 175MM)
Chainrings 40T
Shifters SHIMANO GRX800 11SP
Rear Derailleur SHIMANO GRX800 GS 11SP SHADOW PLUS
Cassette/Freewheel SHIMANO XT M8000 11SP 11-42T
Chain SHIMANO HG 601 11SP
Brakes SHIMANO GRX800
Brake Levers SHIMANO GRX800
Handlebars EASTON EA50 AX (47/50- 420MM, 53/56- 440MM, 59/62- 460MM)
Tape/Grips NINER BAR TAPE
Stem NINER RDO STEM, NINER GRAPHIC (47/50- 80MM, 53/56- 90MM, 59/62- 100MM)
Headset NINER INTEGRATED SHIS DESCRIPTION IS42/28.6|IS52/40
Seatpost NINER RDO SEAT POST, 400MM, NINER GRAPHIC
Saddle NINER CUSTOM WITH CRN-TI RAILS, EMBOSSED NINER GRAPHIC

* Subject to change without notice.

Part Numbers

Option UPC MPN
Black/Bronze / 47cm 001042247200 00-104-22-47-20
Black/Bronze / 50cm 001042250200 00-104-22-50-20
Black/Bronze / 53cm 001042253201 00-104-22-53-20
Black/Bronze / 56cm 001042256202 00-104-22-56-20
Black/Bronze / 59cm 001042259203 00-104-22-59-20
Black/Bronze / 62cm 001042262203 00-104-22-62-20
